Sprocket Replacement
Gear Sprocket Replacement
Replacing the large white gear in your LiftMaster, Sears Craftsman, or Chamberlain garage door opener is a cost-effective, quick, and easy DIY repair. With a few simple hand tools and by following safety precautions, you can get your opener working again. These replacement gears and kits are available online, with various options depending on your needs. Be sure to know whether your opener is chain or belt drive, as different part numbers apply for each.
Gear Options and Kits:
- 41A2817-CR Gear and Grease Only: This option works with all chain and belt drive models from 1984 to the present. It includes the large white gear (2 ¾" x ½" wide, with a ½" bore) and grease. This is ideal for users who only need to replace the main drive gear.
- 41A2817 Complete Kit: In addition to the gear and grease, this kit includes worm gears, replacement bushings, pins, lubricant, and easy-to-follow instructions. It is compatible with all chain and belt drive models from 1984 to the present using the same large white gear (2 ¾" x ½" wide, with a ½" bore).
- 41C4220A Full Kit (Chain Drive Models Only): This kit includes all components in the 41A2817 kit, plus the drive shaft and sprocket. It’s ideal if you don't have the required 5/32” punch, as the main drive gear comes pre-installed on the shaft, making the process more convenient. Note: This kit is only for chain drive models. For belt drive openers, see the following part numbers.
Belt Drive Models:
- 41A4885-2: Use this kit to replace the entire drive shaft and belt pulley assembly on belt drive models from 1984 to 2001.
- 41A4885-5: This kit is for replacing the drive shaft and belt pulley assembly on belt drive models from 2002 to the present.
When choosing a replacement kit, ensure you're selecting the correct part for your specific opener model and type, whether it's chain or belt-driven.
